Suitable for off-grid applications
Stable output of pure sine waves
Support BMS communication
Multiple charge and discharge modes are available
Efficient heat dis sipation: via intelligent adjustable speed fans
High energy efficiency: up to 99.9% MPPT capture efficiency
| Model | HSI 3000S | HSI 3000U | CAN BE SET |
| INVERTER OUTPUT | |||
| Rated Output Power | 3,000W | ||
| Max.Peak Power | 6,000VA | ||
| Rated Output Voltage | 230Vac |
120Vac（L/N/PE Single-phase）
|
Y |
| Load Capacity of Motors | 2HP | ||
| Rated AC Frequency | 50/60Hz | ||
| BATTERY | |||
| Battery Type | Li-ion / Lead-Acid / User Defifined | Y | |
| Rated Battery Voltage | 24Vdc | ||
| Max.MPPT Charging Current | 60A | Y | |
| Max.Mains/Generator Charging Current | 80A | 40A | Y |
| Max.Hybrid Charging Current | 140A | 100A | Y |
| PV INPUT | |||
| Num. of MPP Trackers | 1 | ||
| Max.PV array power | 1600W | ||
| Max.input current | 40A | ||
| Max.Voltage of Open Circuit | 108Vdc | ||
| MAINS / GENERATOR INPUT | |||
| Input Voltage Range | 30~90Vdc | Y | |
| Frequency Range | 50/60Hz | ||
| Bypass Overload Current | 30A | 40A | |
| GENERAL | |||
| Dimensions | 378*280*103mm | ||
| Weight | 6.8kg | ||
| Protection Degree | IP20, Indor OnIy | ||
| Operating Temperature Range | -10℃~55℃ | ||
| Noise | <60dB | ||
| Cooling Method | Forced air cooling with adjustable air speed | ||
