All in One Solar Street Light
RSA Series
Engineered for power and scalability, the RSA Series delivers up to 18,000 lumens with intelligent energy control—ideal for highways, industrial zones, and large-area lighting projects.
Learn More About：
All in One Solar Street Light
Download:
RSA Series
Applications:
| Type | RSA-40-P | RSA-60-M | RSK-100-M | RSA-160-M |
| Solar panel | 60W/6V | 90W/18V | 120W/18V | 160W/18V |
| LiFePO4 battery | 240WH | 432WH | 640WH | 832WH |
| Charge cycle times | 2000 times | |||
| Luminous flux | 5100LM | 9500LM | 13600LM | 18000LM |
| LED qty | 200pcs | 250pcs | 300pcs | 350pcs |
| Beam angle | 150*70 | |||
| Lifespan of LED | 50000 hrs | |||
| Color temperature | 3000-7500K | |||
| Light distribution | Batwing lens with polarized light | |||
| Lighting time | 5-7 rainy days | |||
| Working temperature | -20℃~60℃(Charge above 0℃) | |||
| Top diameter of pole | 60mm | 76mm | ||
| Mounting height | 6-7m | 6-8m | 8-10m | 9-12m |
| Installation spacing | 20-40m | |||
Structure
Mono Solar Panel
High-output monocrystalline array maximises daily energy harvest.
Read More
140 High-Efficiency LED Chips
Dense LED matrix delivers bright, uniform road-class illumination.
Read More
Anti-Corrosion Aluminum Shell
Powder-coated housing resists salt spray, rain and UV for long field life.
Read More
Indicator Light
Built-in status LED offers at-a-glance system health diagnostics.
Read More
Light-Switch Button
On-pole manual override simplifies testing and commissioning.
Read More
Grade-A LiFePO4 Battery
Long-cycle storage ensures stable power and low maintenance.
Read More
Delivery
1、Demand Analysis
● Consultation
● Requirements Confirmation
● Environmental Assessment
2、Solution Design
● Component Selection
● System Configuration
● Preliminary Quotation
3、Raw Material Procurement
● Supplier Selection
● Quality Inspection
● Production
● Packaging
4、Installation
● Civil Works
● Mounting
● System Debugging
5、Client Training
● Operation Training
● Maintenance Workshop
● Documentation Delivery
6、After-Sales Suppor
● 24/7 Helpdesk
● Preventive Maintenance
● Spare Parts Guarantee
7、Feedback Integration
● KPI Monitoring
● Design Iteration
● Client Satisfaction Surveys
More Intelligent Solar Street Light Models
FAQ
What maintenance is required?
Only periodic panel cleaning and visual checks; on-board status LEDs flag any rare faults, keeping lifetime OPEX—and overall all in one solar street light price—low.
How does it cope with heavy-duty sites like highways?
A rugged aluminum chassis, bat-wing optics and single-string MPPT deliver uniform roadway brightness, high wind resistance and long autonomy even in harsh industrial corridors.
Is the RSK an all-in-one solar street light or modular?
RSK is a true all in one solar street light—panel, LiFePO₄ battery, controller and LED are factory-integrated for rapid pole-top mounting.
